BUILT TO BEAR DOWN

MODEL 2570

MODEL 2570
SILAGE TRAILER

A large gray BearClaw 2570 Cargo trailer with black and orange accents, attached to a tractor, featuring warning and hazard markings, rubber tires, and safety equipment.

LOAD CAPACITY:
34,800 KG
76,750 LBS

OPTIONAL FEATURES:

  • Air Brake Kit

  • Manually Operated Grain Doors

  • Rear Hitch with Aux Light Plug

STANDARD FEATURES:

  • SteadyLink Axle

  • DuraSwivel Hitch

  • AdaptaHaul Side Extensions

  • UniLift Hydraulic Dump Cylinder

    (47L / 12.4USG)

  • VibrationShield Tongue System

  • LeanLift Cylinder Kit

  • Hydraulic Brakes

  • Hydraulic Jack

COMPLIANCE READY

Every BearClaw silage trailer is built with your safety in mind. Patented technologies combine with robust protection—road lights, mud flaps, heavy-duty safety chains, and hydraulic jacks come standard. Engineered for compliance, comfort, and reliability, BearClaw keeps your crew protected and every haul secure.

A badge indicating a 1-year warranty on parts with a gold and black design.
Badge indicating a 6-month warranty on labor
Technical drawing of a construction vehicle with detailed measurements and dimensions in yellow annotations.
BearClaw 2570
Load Capacity Overall Length
- A -		 Overall Height
- B -		 Overall Height
(Extension Down)
- C -		 Overall Height
Tipped
- D -		 Overall Height Tipped
(Extension Down)
- E -		 Tongue Length
- F -		 Overall Width
- G -		 Grain Volume Silage Volume Empty Tongue Weight Approx. Weight
lbs kg Inches Inches Inches Inches Inches Inches Inches Bushels Cubic Feet Cubic Meters lbs kg lbs kg
76,750 34,800 490 162 128 400 381 92 133 1,276 2,558 72 2,211 1,005 32,000 14,550

BEARCLAW TECHNOLOGIES

The image shows the underside of a heavy-duty dump trailer with large off-road tires, hydraulic support struts, and a black container bed raised to an angle for dumping.

UniLift Hydraulic Dump Cylinder

  • The UniLift Hydraulic Dump Cylinder uses a single multi-stage design that eliminates large hydraulic systems and complicated controls while reducing maintenance and fluid requirements for reliable, cost-effective dumping power.

Close-up of a trailer hitch with a warning label, metal bolts, and a black painted coupling component.

DuraSwivel Hitch

  • The DuraSwivel Hitch twists to conform to terrain while providing critical rollover protection, keeping your towing vehicle upright by letting the trailer roll independently for maximum operator safety.

Close-up view of a hydraulic system with hoses, fittings, and a large black cylinder, likely part of a construction or industrial machinery.

LeanLift Cylinder Kit

  • Our patented LeanLift Cylinder Kit reduces hydraulic fluid requirements up to 52% across our 1850, 2260, and 2570 units without sacrificing dumping performance. This breakthrough engineering eliminates the need for oversized hydraulic systems and auxiliary pumps, streamlining your operation while reducing maintenance demands and fluid costs.

    By optimizing cylinder efficiency and flow dynamics, this innovative system provides confident, reliable dumping capability that adapts to your equipment rather than forcing costly upgrades. The result is reduced operational complexity, lower infrastructure investment, and dependable field performance that keeps your operation running efficiently season after season.

Close-up of a gray industrial machine with yellow accents and perforated metal panels.

AdaptaHaul Side Extensions

  • Our AdaptaHaul Side Extensions provide on-demand trailer versatility through patented quick-shift technology that transitions between grain and silage configurations. This innovative system eliminates costly equipment redundancy while ensuring optimal load containment for diverse hauling applications.

Close-up of a mechanical or industrial component, including a large metal pipe, bolts, and a rubber part labeled 'TIMKEN MADE IN CANADA,' mounted on a metal frame.

VibrationShield Tongue System

  • Our VibrationShield Tongue System dampens vibrations and eliminates shock from shifting loads, providing smooth, confident towing while reducing vehicle wear and protecting operator comfort.

Close-up of large off-road tires on a construction vehicle with black body and orange ladder, branded 'AvantClou'.
Gold and black promotional badge with bold text reading "Exclusive to the 2570".
Remote control with blue casing, yellow buttons for controls labeled 'UP,' 'DOWN,' 'JACK,' 'AXLE,' 'FLIPPER,' and 'UP,' with additional labels 'TEACH,' 'BATT,' 'ON,' and 'BASS' engraved on the casing.

RemoteCommand With Autoalign

  • Advanced electronic steering continuously monitors tie rod angle, wheel speed, and axle position to deliver precise tri-axle control in any condition. Real-time data feeds the steering controller, managing electric-over-hydraulic valves for smooth operation—even when reversing with a full load. The system automatically engages free steering above 25 km/h for safe road transport, while a wireless keypad provides manual override and calibration control, giving you complete command from inside or outside the cab.

    Integrated electric valve architecture streamlines operation by controlling the front extension, jack, and lift axle through a single remote outlet, reducing hydraulic demands on your tractor. The front lift axle provides full articulation during field work, then raises to minimize tire wear when running empty on the road. The system adapts to your setup, operating with standard remote valves or power-beyond configurations for optimized power management.

A tractor with a front loader spreading fertilizer into a large trailer, on a cornfield with rows of green and yellow corn plants.

FlipDeploy System

  • Deploy your hydraulic front extension in seconds to blow silage directly behind the harvester and into the trailer. Perfect for challenging field conditions, narrow rows, and constrained areas where standard side-loading won’t work—keeping your operation moving.

Close-up of large off-road tires and vehicle suspension components viewed from underneath, showing the underside of a rugged vehicle with heavy-duty tires and mechanical parts.

SteadyLink Axle

  • The triangulated linkage system with stub axles ensures smooth, safe transport under heavy silage loads, while the 10-bolt hub interface delivers unwavering strength and stability. This proven design provides the confidence to haul big loads with simplified maintenance that reduces downtime and service costs.
